Screening results
Type
Connector
Poles
2 to 12P
Pitch
2.5mm
Material - Resin and Flammability
Nylon 66 UL 94V-0 or UL 94V-2
Voltage - Maximum
250V AC/DC
Current - Maximum per Contact(Max)(A)
3.0A AC/DC
Material
Phosphor bronze
Wire Size(AWG)
28-22
Type
Connector
Poles
2 to 12P
Pitch
2.5mm
Material - Resin and Flammability
Nylon 66 UL 94V-0 or UL 94V-2
Voltage - Maximum
250V AC/DC
Current - Maximum per Contact(Max)(A)
3.0A AC/DC
Material
Phosphor bronze
Wire Size(AWG)
28-22
Type
Connector
Poles
2 to 12P
Pitch
1.25mm
Material - Resin and Flammability
Nylon 66 UL 94V-0
Voltage - Maximum
50V AC/DC
Current - Maximum per Contact(Max)(A)
1.0A AC/DC
Wire Size(AWG)
32-28
Pin
Phosphor bronze tin-plated
Type
Connector
Poles
2 to 12P
Pitch
1.25mm
Material - Resin and Flammability
Nylon 66 UL 94V-0
Voltage - Maximum
50V AC/DC
Current - Maximum per Contact(Max)(A)
1.0A AC/DC
Wire Size(AWG)
32-28
Solder tabs
Tin-plated brass
Pin
Phosphor bronze tin-plated
Type
Connector
Poles
2 to 12P
Pitch
2.5mm
Material - Resin and Flammability
Nylon 66 UL 94V-0
Voltage - Maximum
250V AC/DC
Current - Maximum per Contact(Max)(A)
3.0A AC/DC
Wire Size(AWG)
28-22
Type
Connector
Poles
2 to 12P
Pitch
2.54mm
Material - Resin and Flammability
Nylon 66 UL 94V-2
Voltage - Maximum
250V AC/DC
Current - Maximum per Contact(Max)(A)
3.0A AC/DC
Wire Size(AWG)
28-22
Type
Connector
Poles
2 to 12P
Pitch
3.96mm
Material - Resin and Flammability
Nylon 66 UL 94V-0
Voltage - Maximum
250V AC/DC
Current - Maximum per Contact(Max)(A)
7.0A AC/DC
Wire Size(AWG)
24-18
