Screening results
Type
Connector
Poles
2 to 16P
Pitch
3.96mm
Material - Resin and Flammability
Nylon 66 UL 94V-0
Voltage - Maximum
250V AC/DC
Current - Maximum per Contact(Max)(A)
7.0A AC/DC
Material
Phosphor bronze
Wire Size(AWG)
22-18
Pin
Tin-plated brass
Type
Connector
Poles
2 to 6P
Pitch
3.96mm
Material - Resin and Flammability
Nylon 66 UL 94V-0
Voltage - Maximum
250V AC/DC
Current - Maximum per Contact(Max)(A)
8.0A AC/DC
Material
Phosphor bronze
Wire Size(AWG)
20-16
Type
Connector
Poles
2 to 6P
Pitch
3.96mm
Material - Resin and Flammability
Nylon 66 UL 94V-0
Voltage - Maximum
250V AC/DC
Current - Maximum per Contact(Max)(A)
8.0A AC/DC
Material
Phosphor bronze
Wire Size(AWG)
20-16
Type
Connector
Poles
2 to 16P
Pitch
3.96mm
Material - Resin and Flammability
Nylon 66 UL 94V-0
Voltage - Maximum
250V AC/DC
Current - Maximum per Contact(Max)(A)
5.0A AC/DC
Wire Size(AWG)
22-18
Pin
Tin-plated brass
Type
Connector
Poles
2 to 12P
Pitch
3.96mm
Material - Resin and Flammability
Nylon 66 UL 94V-0
Voltage - Maximum
250V AC/DC
Current - Maximum per Contact(Max)(A)
7.0A AC/DC
Wire Size(AWG)
24-18
Type
Connector
Poles
3P
Pitch
3.96mm
Material - Resin and Flammability
Nylon 66 UL 94V-0
Voltage - Maximum
300V AC/DC
Current - Maximum per Contact(Max)(A)
10A AC/DC
Wire Size(AWG)
26-18
