Screening results
Type
Connector
Poles
2P,3P,4P,6P,9P,12P,15P
Pitch
4.5mm
Material - Resin and Flammability
Nylon 66 UL 94V-0
Voltage - Maximum
300V AC/DC
Current - Maximum per Contact(Max)(A)
10-6A AC/DC
Material
Phosphor bronze
Wire Size(AWG)
26-18
Type
Connector
Poles
2P,3P,4P,6P,9P,12P,15P
Pitch
4.5mm
Material - Resin and Flammability
Nylon 66 UL 94V-0
Voltage - Maximum
300V AC/DC
Current - Maximum per Contact(Max)(A)
10-6A AC/DC
Material
Phosphor bronze
Wire Size(AWG)
26-18
Type
Connector
Poles
2P,3P,4P,6P,8P,9P,12P,15P
Pitch
4.5mm
Material - Resin and Flammability
Nylon 66 UL 94V-0
Voltage - Maximum
300V AC/DC
Current - Maximum per Contact(Max)(A)
7-3A AC/DC
Material
Phosphor bronze
Wire Size(AWG)
26-20
Type
Connector
Poles
2P,3P,4P,6P,8P,9P,12P,15P
Pitch
4.5mm
Material - Resin and Flammability
Nylon 66 UL 94V-0
Voltage - Maximum
300V AC/DC
Current - Maximum per Contact(Max)(A)
7-3A AC/DC
Material
Phosphor bronze
Wire Size(AWG)
26-20
Type
Connector
Pitch
4.5mm
Voltage - Maximum
250V AC/DC
Current - Maximum per Contact(Max)(A)
3.0A AC/DC
Wire Size(AWG)
20-14
Type
Connector
Poles
2P,3P,4P,6P,9P,12P,15P
Pitch
4.5mm
Material - Resin and Flammability
Nylon 66 UL 94V-0
Voltage - Maximum
300V AC/DC
Current - Maximum per Contact(Max)(A)
10-6A AC/DC
Wire Size(AWG)
26-18
